Yom : 2002 — Refurbished in 2010.
Maximum opening between new wheels 250 mm
Recommended working range 5-175 mm
Maximum workpiece length for infeed grinding, normal wheels 605 mm
Maximum workpiece length for infeed grinding, recessed wheels 695 mm
Grinding Wheel
Outer diameter, new wheel, standard/maximum 610/630 mm
Outer diameter, worn wheel 380 mm
Normal width 610 mm
Maximum width, with recessed wheel 700 mm
Boron diameter 304.8
Peripheral speed max 63 m/s
Grinding Wheel Headstock
Resolution, servomotor 0.1 μm
Max. feed rate, servomotor 10 mm/s
Regulating Wheel
Outer diameter, new wheel, standard/maximum 330/380 mm
Outer diameter, worn wheel 255 mm
Normal width 610 mm
Maximum width, with recessed wheel 660 mm
Resolution, servomotor (headstock) 0.1 μm
Boron diameter 203
Speed 10-750rpm
Regulating wheel’s maximum inclination 5 °.
Power requirements
Main motor 37-100 kW
Dimensions & Weights 1060 mm
Footprint 6,000 x 2,800 mm
Net weight 13 500 kg
