| CNC : | Siemens 840D |
| Nominal workpiece diameter : | 2000 mm |
| Stroke Axis X : | 1250 mm |
| Stroke Axis Z : | 1600 mm |
| Storke Axis Y : | 300 mm |
| Min/max distance between table centre and wheel center : | 100/1350 mm |
| Axis A - Head Swivelling : | +/- 45° |
| External Grinding head power : | 50 Kw |
| Speed range : | Max 4000 min-1 |
| Profilme grinding wheel max dimensions : | 100x450mm |
| Table diameter : | 1460 mm |
| Integrated automatic balancing device : | |
| Max part weight : | 20 000 Kg |
| Internal head power : | 20kw |
| For straight and helical gears – swivel inclinaison : | +/-30° |
| Adjustable drive range : | 1200- 4000 rpm |
| Max grinding length : | 700mm |
| OPTION : | |
| Gear measurment for external toothed workpiece : | |
| NC Dressing device : | |
| Softawre for fauft diagnosis : | |
| External and internal heads : | |
| Cooland and filtration system HOFFMANN : |
SOLD
CNC Gear Grinding Machine – GLEASON PFAUTER P2000G
| Brand : | GLEASON PFAUTER |
| Model : | P2000G |
| Year : | 2010 |
