Features
:
Maximum diameter and grinding and control: 600mm
Max. module approx. 15mm (profile depth 35mm)
600mm axial stroke
Propeller angle +/-45
Dressing wheel from Ø 170 to 300 – max width 50mm
Table bore Ø 125mm, depth 450mm
Maximum table load 1200kg
Weight of the machine about 11T
Equipment:
Siemens 840C CNC
Counter-mounting – automatically removable by NC axis for use as a workpiece loader or workpiece Ø > 600mm
3-circuit filter and cooler unit
Options
Error diagnosis
Leveling wedges
Integrated NC Dresser
Automatic wheel balancing
Diagnosis by phone (Analog modem)
Centering probe (Renishaw )
Integrated gear control (profile, helix, pitch, runout, ball rib) with Renishaw probe
Rotating tailstock
Oil mist vacuum cleaner
Sensor for automatic centering (for series)
Automatic grinding strategy (the machine proposes a cycle strategy)
Foot and head Ø control
Heating program
Hydraulic pot
2 grinding wheel holders
