Grinding diameter: 10 – 200 mm
Grinding depth: 200 mm
Tip height: 280 mm
Pivoting headstock : 30°.
Passage diameter: 350 or 500 mm
Shaft nose inner cone: Metric 70
Four workpiece headstock speeds: 180-300-500-850 rpm
Maximum displacement of the treadmill table: 120 mm
Minimum / maximum grinding table travel: 3 / 500 mm
Weight of the machine : 4.3 T
