TECHNICAL DATA
max. diameter above the bench: 583 mm
max. diameter above the carriage: 300 mm
distance between centres: 1800 mm
max. diameter in spindle: 82 mm
spindle speed : 2500 rpm.
type of spindle : A1-8 ”.
stroke : 282 x 1710 mm
tailstock type : KM 6
sleeve stroke: 285 mm
sleeve diameter: 100 mm
dimensions: 3620 x 1400 x 1830 mm
weight: 2800 kg
EQUIPMENT
CN CAZENEUVE
PL+S3 3-jaw chuck Ø250 mm
MULTIFIX tool turret type C (25 x 25 mm)
lubrication tank with pump
