Year: 2006
CN: NUM with profile version
Ø allowed above the bench: 360 mm
Ø allowed above the cross slide: 200 mm
Distance between warehouses: 610 mm
Bench width: 330 mm
Spindle :
Spindle nose diameter 140 mm
Spindle bore Ø: 54 mm
Standard tailstock with a crankable barrel
VDI 20 turret, 8 stations
Specifications
Spindle speed (continuously variable): 4,200 rpm
Spindle motor power: 7.5 kW
Power supply: 400 volts
Dimensions (L x W x H): 1950 x 1320 x 1840 mm
Weight 2T1
Large batch of VDI tool holders and pliers
No chuck
Technical description without guarantee, only for information purposes
