Control: FANUC 16.Oi MB 6 axis controlled
Workpiece nominal diameter: 200mm
Workpiece wing max: 350 mm
Maximum module: 6
Shaper head (W axis) -25° / +10° tilt
Stroke : 110 mm
Riser block for cutter column : 100 mm
Hydrostatic spindle guide -spur guide
Workpiece clamping hydraulic
Tailstock
2 carousel ring loader stations
20 position carousel conveyor
MPG electronic handwheel
Ethernet Gleason teleservice
Work chamber air filter smoke and mist
Chip removal system opposite operator position
Tool type: HSK B63
Feed and rapid traverse rates max : axial 2000 mm/min – radial 5000mm/min
Cutter spindle drive motor : 12 kW
Retractable deburr unit
Working cutting hours : 6515h
Made in USA – No CE mark
