Modul mini/maxi : 1 to 8 mm
Center distance min to max : 119 to 329 mm
Shaving cutter diameter min to max : 180 to 254 mm
Cutter centering diameter : 63.5 mm
Cutter rotation : 10 to 400 RPM
Axis X feed : 1 to 750 mm/min
Stroke X axis : +/- 35 mm
Axis U feed: 500 Degrees/min
Axis Z feed: rapid 375 mm/min — Work 0.1 to 4 mm/min
Strok Z: 210 mm
Axis Y feed 1 to 750 mm/min
Strok Y axis: +/- 120 mm
Axis W feed: 1 to 750 mm/min
Strok W axis: +/- 30 mm
Equipped with an autoloader
