Year 2004
CE standard
CNC FANUC 18i TB HVI
Maximum turning diameter: 400 mm
EP: 692 mm
Max. diameter bars: 66 mm
Chuck diameter: 210 mm
Pin: A2 ‘6’.
Spindle bore: 73 mm
Fast X/Z: 18/24 m/min
Main spindle speed: 4,000 rpm
Milling spindle speed : 4 000 rpm
Main spindle motor power: 22 kw
Milling spindle motor power: 12 kw
12-station turret
Chip conveyor
Weight of the machine 5500Kg
