Number of axes: 3
MAIN SPINDLE
– Spindle nose: A2-8
– Spindle power: 25/18 kW
– Spindle speeds: 50-3500 rpm
– Maximum bar diameter: 77 mm
– Maximum machinable diameter: 400 mm
– C axis indexing accuracy: 0.001 °.
TOURELLE
– Number of positions: 12
– Number of motorized positions: 12
– Stroke X/Z: 240/640 mm
– Tool type: VDI 40
– Rotating tool speed: 4000 rpm
– Rotating tool power: 5/3.8 kW
COUNTER POINT
– Type of tailstock
– Cone type
– Tailstock stroke: 520 mm
– Distance between spikes: 676 mm
POWER SUPPLY
– Supply voltage: 380 V
– Installed power: 50 kW
MACHINE HOURS
– Hours under power: 20600 h
– Working hours: 8530 h
Equipment:
– CNC: 18i-TB
– Irrigation tank: 240 [l]
– Oil mist vacuum cleaner
– Loading/unloading robot
– 3-jaw chuck
