Number of axes: 3
MAIN SPINDLE
– Spindle nose: A2-8
– Spindle power: 40/25 kW
– Spindle speeds: 50-3500 rpm
– Maximum bar diameter: 76 mm
– Maximum machinable diameter: 400 mm
– C axis indexing accuracy: 0.001 °.
VDI 40 TURRET
– Number of positions: 12
– Number of motorized positions: 12
– Stroke X/Z: 240/640 mm
– Tool type: VDI 40
– Rotating tool speed: 4000 rpm
– Rotating tool power: 12 kW
COUNTER POINT
– Digital tailstock type
– Cone type CM5
– Quill stroke 120 mm
– Distance between spikes: 676 mm
POWER SUPPLY
– Supply voltage: 380 V
– Installed capacity: 50 kVA
Equipment:
– CNC: 31i-A
– Tank: 240 [l]
– Loading/unloading robot 2X10 kg
– Interchangeable hands option (allows the loading of axes or slugs)
– Paddle with 14 vanes for an ever increasing range
Storage capacity: max diameter 280 mm, 500 mm stacking, 75 kg per pallet
– Parts recovery system
– 3-jaw chuck
– Two rotating tool holders (radial and axial)
Technical description without guarantee, only as an indication.
