– Number of axes: 3
MAIN SPINDLE
– Spindle nose: A2-8
– Spindle power: 25/18 [kW]
– Spindle speeds: 50-3500 [tr/min]
– Maximum bar diameter: 77 [mm]
– Maximum machinable diameter: 400 [mm]
– C axis indexing accuracy: 0.001 [°]
TOURELLE
– Number of positions: 12
– Number of motorized positions: 12
– X/Z stroke: 240/640 [mm]
– Tool type: VDI 40
– Rotating tool speed: 4000 [tr/min]
– Rotating tool power: 5/3.8 [kW]
COUNTER POINT
– Type of tailstock
– Cone type
– Tailstock stroke: 520 [mm]
– Distance between points: 676 [mm]
POWER SUPPLY
– Supply voltage: 380 [V]
– Installed capacity: 50 [kW]
MACHINE HOURS
– Hours on: 20600 [h]
– Hours worked: 8530 [h]
Equipment
– CNC: 18i-TB
– Irrigation tank: 240 [l]
– Chip conveyor
– Oil mist vacuum cleaner
– Loading/unloading robot
– 3-jaw chuck
