NUM PL+S digital control
Technical characteristics :
Maximum diameter over the bench: 500 mm
Distance between centres: 1500 mm
Maximum diameter over the cross slide: 440 mm
Spindle bore: 72 mm
Longitudinal stroke: 1406 mm
Transverse stroke: 267 mm
Spindle speed 2500 rpm
Fast speed 9 m/min
Spindle motor 15 kw
Weight 6800 kg
Dimensions 3100x1800x1800 mm
Manual turret
