CNC milling machine SAMPUTENSILI S 130 Year : 2000 CNC SIEMENS 840 C
Technical specifications:
Max. workpiece diameter 130 mm
Max. module: 3 mm
Table diameter: 132 mm
Cutter speed: 250-3500 rpm
Head tilt +/- 40°.
Dimensions of the milling cutters (diam x length) 80 x 240 mm
Table rotation: from 5 to 1000 r/min
Main motor power 15 kW
Feed rates: 0,1 – 2000 mm/min
Tangential stroke: 200 mm
Radial stroke: 10 / 100 mm
Axial stroke: 300 / 200 mm
Accessories :
Automatic loader
Magnetic chip conveyor
Clamping device
