– Max. tool length: 300 [mm]
* for 3/4 drills (max. diameter 25.4 mm): 950[mm]
* if loaded by robot :195[mm]
* if loaded by machine axes :140 [mm]
– Max. tool diameter: 150 [mm]
* if no peripheral machining (e.g. Fellows knives): 300[mm]
– Rotating axes of the headstock (A axis)
* speed range: 0 to 800 [t/mm]
* landing cone: SA50
– Grinder spindle
* inclination of grinding wheel head (B axis): 240 [°].
* wheel diameter: 125[mm] (200 mm without wheel changer)
* max speed: 25 000 [min-1]
* Pmax power: 13 to 25 [kW]
* attachment cone: HSK50 and HSK63
Equipment
– Numaffut 4.87 software
– SCARA STAUBLIN robot for parts change
– 5-position grinding wheel changer
– ELABRON electrostatic vacuum cleaner
– Blowing tool
– Retention bin
– 600 litre filtration unit with 10 bar pump
– RENISHAW probe, fixed, straight
– SECO master 250 measuring bench connected to the machine
– 39 pallets of 10 tools
– 12 HSK hubs diam 20 – 8 medium and 4 long
– 2 SCHUNK auto chucks Diam 20 and 32 mm
