– Part diameter : 100 [mm]
– Nominal module
* gear hobbing : approx. 3.0 [mm]
* endless screw milling : approx. 8.0 [mm]
– Max. axial movement : 320 [mm]
– Cutting head orientation: -45 / + 115 [°]
– Main mill max. diameter : 118 [mm]
– Max. cut out length of the mail mill : 180 [mm]
– Max. mill movement ( Shifting) : 160 [mm]
– Max. part-holder spindle speed : 3000 [t/mm]
– Min/max distance between axes : 10/100 [mm]
– Cutting head motor power : 14 [kW]
– Main mill speed : 50-12000 [t/mm]
– Weight : 5000 [kg]
Equipment
– Siemens 840D CNC
– Cooling tank
– Chip conveyor
