Number of axes: 4
MILLING SPINDLE
– Type of tool holder: ISO 50
– Spindle power: 22 [kW]
– Spindle speeds: 6000 [tr/min]
LINE AXES
– X/Y/Z axis travel: 1250 x 1000 x 1000 [mm]
– Fast forward speeds (X/Y/Z): 24.000 [mm/min]
– Working feed speeds (X/Y/Z): 12000 [mm/min]
TOOL CHANGER
– Tool magazine capacity: 90
– Tool change time: 2.5 [sec]
PALLET CHANGER
– Time to change pallet: 29 [sec]
– Pallet size : 800 x 800 [mm]
– Number of pallets : 2
– Permissible weight on pallet: 1.600 [kg]
– Pallet to spindle axis distance (min/max): 106 [mm]
– Distance center pallet / spindle nose (min/max) : 120 [mm]
DIMENSIONS
– Floor dimensions: 3,600 x 6,250 [mm]
– Machine height: 3230 [mm]
– Machine weight: 20,500 [kg]
– CNC : FANUC 18i-MB
– Sprinkler tray
* with high pressure pump
* Watering of the spindle center
– Chip conveyor
– Spindle cooling
