-Clean tank volume 6000 litres
-Max. filtration rate 850 l/min
-Maximum dispensing rate 800 l/min
MP pump (number 3)
7,5 kw — 15 m3/h — 8 bar
HP pump (number 3)
11 kW — 9m3/h — 15 bar
Filter pump (number 2)
4 kW — 51 m3/h — 0.8 bar
Washing pump (quantity 1)
5,5 kW — 9,6 m3/h — 6 bar
Cold pump (number 1)
2.2 kW — 9.6 m3/h — 2.2 bar
Lifting pump (quantity 2)
3 kW — 25,8 m3/h — 0,6 bar
Supply voltage 400 V three-phase
EURODIFROID cooler characteristics (year 2007)
– Cooling type: oil
– Minimum/maximum fluid temperature: 10°– 25°.
– Min/max room temperature: 10°– 45°.
– Min/max flow rate: 50 l/min — 160 l/min
– Minimum/maximum operating pressure: 1.9 bar — 2.9 bar
– Refrigerant / quantity: R407C / 9000 kg
– Voltage 400 V
– Cooling capacity 34500W
– Tank volume 150 L
