Maximum distance between spikes: 735 mm
Minimum/maximum distance between milling cutter/piece: 30/195 mm
Maximum diameter and length of the motherboard: 130*130 mm
Max. gear diameter : 250 mm
Maximum cutting length: 335 mm
Minimum number of teeth: 6
Shifting
Maximum shifting stroke: 100 mm
Progressive and continuous plunge feed 0 to 3 mm
Diameter of the dividing wheel: 320 mm
Machine size: 1715*1060*1750
Weight : 4000Kg
