CNC SIEMENS 840C
Table diameter: 450 mm
Table bore: 125 mm
Table speed: 22 min-1
Maximum workpiece diameter 800 mm
Vertical travel (Z-axis): 600 mm
Maximum module: 16
Tangential stroke (Y-axis): 150 mm
Radial stroke (X-axis): 600 mm
Head tilt: +/- 45
Dimension of the grinding wheel: 300 x 80 x 80 mm
Grinding wheel speed: max. 8,000 min-1
Weight of the machine. 12 500Kg
Integrated RENISHAW measuring probe
