Max. Gear diameter / Workpiece swing : 400/500 mm
Hobbing length : 310 mm
Max. module : 6/8
Minimum no. of teeth : 6
Distance between tool and workpiece axis: 20 – 340 mm
Extended tailstock
Table diameter : 400 mm
Boron table: 80 mm
Swing angle: 240°.
Hob Ø x length : 163 x 280 mm
Hob shifting, max. : 170 mm
Hob spindle speeds, infinitely variable 40 – 240 rpm
Feed range, axial, infinitely variable 0.42 – 2,40 mm/rev
radial, infinitely variable 0,10 – 1,9 mm/rev
tangential, infinitely variable 0,18 – 3,15 mm/rev
Weight of machine, : 7,000 kg
