Normal distance between centres (centres to the rear) 750 mm
Max. Distance between centres (centre in clamping head) 1200 mm
Grinding length 500 mm
Workpiece Ø, min/max 10 – 350 mm
Working hole bore 130 mm
Workpiece speed, infinitely variable 1 – 26 rpm
Lead range, min/max 1 – 500 mm
Max. Lead angle 45°.
Pressure angle 0 – 30°.
Module range 0.5 – 25
Number of wires 1 – 30
Grinding depth 65 mm
Grinding wheel dimensions, Ø x width 500 x 60 mm
Wheel speeds, infinitely variable 75 – 3000 rpm
Weight 8,500 kg
Accessories :
Diamond dressing unit
10 grinding wheels
