TECHNICAL SPECIFICATIONS :
Grinding diameter: 25 – 300 mm
Grinding depth: 250 or 350 mm
Tip height: 300 mm
Diameter of passage in the protection: 350 or 500 mm
Headstock passage : 70 mm
6-speed headstock: 30 – 500 rpm
Maximum tilt of the headstock: 30°.
Maximum table travel: 600 or 900 mm
Minimum table travel: 3 mm
Proportional table speed: 0 – 10 m/min
Number of spindle revolutions: 3000 – 20 000 rpm
Spindle diameter: 120 mm
Power requirement: 10-14 hp
Approximate net weight: 4000 – 4500 kg
