Year: 02/2006
CNC Fanuc G-tech 30i
BT50 Cone
120 tool magazine
Number of pallets : 2
4 axes – 360.000° indexing
Spindle 12,000 rpm
X,Y,Z travels: 1050 x 920 x 870 mm
Distance centre pallet/spindle: 150 -1020 mm
Distance flat surface / spindle centre 75-995 mm
Pallets: 800 x 800 mm
Maximum pallet weight 1200kg
Max. workpiece dimensions: 1050 x 1000 mm
Probe
Machine size: 6200 x 4200 x 3300 mm
