Number of axes: 5
MILLING SPINDLE
Toolholder type: HSK-A-100
Spindle power: 50 kW
Spindle speeds: 6000 rpm
Gearbox : 2
Speed range: 20-1028/1028-6000 rpm
LINE AXES
X/Y/Z axis travel: 1450/1100/1300 mm
Rapid feed speeds (X/Y/Z): 65 m/min
Working feed speeds (X/Y/Z): 1-65 m/min
ROTARY AXIS B: H/V head
Stroke: 180°.
Indexing accuracy: 180°.
ROTARY AXIS C: table
Stroke: 360
Indexing accuracy: 0.001°.
Fast forward speed: 60 rpm
TOOL CHANGER
Type of tool changer: Loader arm
Tool magazine capacity: 180
Tool change time: 5.5 sec
PALLET CHANGER
Type of pallet changer : Rotopallet
Pallet change time: 18 sec
Pallet size : 800 X 1000 mm
Number of pallets : 2
Permissible weight on pallet: 2000 kg
Maximum workpiece diameter: 1400 mm
Max. room height: 1400 mm
POWER SUPPLY
Supply voltage: 400 V
DIMENSIONS
Floor dimensions : 8100 X 5350 mm
Machine height: 4150 mm
Machine weight : 25000 kg
