Number of axes: 5
MILLING SPINDLE
Toolholder type: HSK-A-100
Spindle power: 37 / 53 kW
Spindle speeds: 12,000 rpm
LINE AXES
X/Y/Z axis travel: 1700/1600/1950 mm
Rapid feed speeds (X/Y/Z): 45 m/min
ROTARY AXIS A: head
Stroke: -100 / +60°.
Indexing accuracy: 0.001°.
Fast forward speed: 6 rpm
ROTARY AXIS B: table
Stroke: 360
Indexing accuracy: 0.001°.
Fast forward speed: 5.5 rpm
TOOL CHANGER
Type of tool changer: Loader arm
Tool magazine capacity: 180
PALLET CHANGER
Type of pallet changer : Linear
Pallet size : 800 X 800 mm
Number of pallets : 2
Permitted weight on pallet: 3000 kg
Maximum workpiece diameter: 1700 mm
POWER SUPPLY
Supply voltage: 400 V
DIMENSIONS
Floor dimensions : 9500 X 7800 mm
Machine height: 4550 mm
Machine weight: 42,000 kg
