Maximum passage diameter : 1600 mm
Maximum turning diameter : 1600 mm
Maximum turning height: 500 mm
Work table dimensions: 1250 mm
Maximum table load : 5000 Kg
Cross travel (X axis) 2260 mm
Vertical travel of the boom (Z axis) 1100 mm
Spindle speed, ranges: 2-350 Auto-High-Low
Maximum spindle torque: 11179 Nm
Rapid feed (X/Z axis): 12/10 m/min
Number of tools: 60
Type of attachment: CAPTO C8
Maximum tool size: 120 (diameter) * L300 mm
Maximum tool weight : 20 Kg
Maximum load of the tool changer : 720 Kg
Tool change time: 50 sec
Square tool holder: square 32*32
Turret:
RAM square section: 300*300 mm
Table spindle motor 51 / 81 Kw
Servo motor (X/Z axis) 7.0/7.0 Kw
Machine weight : 34 000Kg
Floor space: 6630*10775*6450
