Pulling force: 80kN
Broaching stroke (max.): 1250mm
Spindle feed stroke (max.) : 500mm
Spindle lengths: 650-1400mm
Table top width: 400mm
Pinning speed (max.): 1-10m/min
Return stroke speed (max.): 1-15m/min
Weight of the machine : 4300kg
Weight of the electrical cabinet : 400kg
Power: 25kW
