YOM: 1996
hobbing length : 1750 mm
milling width : 260 mm
max. module 8
profile spindle diameter : 45 mm
min/max milling cutter dia. 115-160 mm
Table dimensions: 460 x 2,100 mm
Clamping surface table : 250 x 1.850 mm
Speed feeds : 0 – 500
Spindle speed range rpm : 29 – 178 rpm
spindle head swivable left – right : 90 – 10 °
total power requirement : 5kW
weight of the machine ca. : 3500 t
dimensions of the machine ca. 4 x 1.8 x 1.8 m
