Technical specifications:
CN FANUC 21i
Strokes X: 800 mm; Y: 510 mm; Z: 630 mm
Table size: 950 mm x 510 mm
Weight capacity on table: 500kg
Rapid feeds X/Y axis = 30M/min; Z axis = 24M/min
Spindle speed: 10000 rpm – pulley
Tool changer ATC24 – BT40
Spindle power: 11 KW
Spindle center watering 20 Bars
Machine dimensions: 2960 x 2470 mm
Weight: 4300 kg
Equipment :
Chip conveyor + crankcase washing
Centralized lubrication
Work lamp
4th Axis type Tsudakoma 250 mm (Model RN-250R)
Spindle cooling and pressurization
Electronic handwheel
Rigid tapping option
RS232 socket
