Maximum diameter : 300 mm
Maximumwidth: 695 mm
Max. module : 10 mm
Minimum number of teeth : 4
Centre distance: 875 mm
Distance tool – workpiece: min / max: 50/170 mm
Spindlebore : 141 mm
Max. cuttinglength 170 mm
Diameter of the cutter : 150 mm
Shifting : 60 mm
Rotational speeds of the milling cutter : from 35 to 180 rpm
Axial stroke: 0.25 – 4 mm / U
Radial stroke : 0,175 – 1.0 mm / U
Total power: 5,5 kW
Weight of the machine ca.: 4,5 t
Machinedimensions: 2450 x 2450 x 1800 mm
