Max. Cutting length 2.100 mm
Milling travel / milling width cross max. 300 mm
Maxi Module in steel 16
Table clamping size 510 x 2,400
Mounting height under cutter, depending on cutter Ø 150 430 mm
Cutter Ø, min./max Ø 125 + 2 x cutting depth / Ø 280 mm
Cutter width max. without/with counter bearing support 50 / 140 mm
Cutter mandrel Ø max. 50 mm
Milling spindle head, swivelling ( for relief cuts ) right / left 30 / 45 °
Milling spindle speeds steplessly adjustable 40 120 rpm
Milling slide swivelling right / left for Helix Cuts 30
Feeds, infinitely variable (milling slide) 0 1.300 / 2.000 mm/min
Quick return of WP-table 10.000 mm/min
