Capabilities:
Maximum diameter of passage on bench 450 mm
Maximum passage diameter on trolley 290 mm
Maximum machinable diameter between centers 290 mm
Carriage length 330 mm
Spindle:
Spindle nose type A2 5”.
Spindle bore 45 mm
Spindle speed 6,000 rpm
Spindle motor :
Maximum power 16 Kw
Turret:
Chair type 10 positions
Turning tool cross section 20 x 20 mm
Counter point:
Stroke 80 mm
Cone of the CM3 sleeve
Footprint :
Length 2,451 mm with conveyor belt
Width 1,335 mm
Height 1727 mm
Weight 2T6
Equipment:
Pliers holder chuck + set of pliers
Set of tool holders
Conveyor
Watering pump
Documentation
Technical description without guarantee, only for information purposes
