Capabilities:
Maximum diameter of passage on bench 600 mm
Maximum passage diameter on trolley 400 mm
Maximum machinable diameter between centers 330 mm
Carriage length 540 mm
Spindle:
Spindle nose type A2 6” ISO
Spindle bore 65 mm
Spindle speed 4,500 rpm
Spindle motor :
Maximum power 16 Kw
Turret:
Type VDI 40 12 positions
Turning tool cross section 25 x 25 mm
Rotating tool power. 5,5 Kw. 4000 tr
Counter point:
Stroke 100 mm
Cone of the CM4 sleeve
Footprint :
Length 4100 mm with conveyor belt
Width 1745 mm
Height 1890 mm
Weight 5T6
Equipment:
Autoblock 3-jaw chuck type BB diameter 210 mm
Set of fixed and rotating tools (radial rotating tools x 2 + axial tools x 2 + fixed tools x 12)
Conveyor
Tool probe
5 bar pump
Documentation
Technical description without guarantee, only for information purposes
