Machinable diameter above the bench: 550 mm
Machinable diameter of the wicket : 420 mm
Spacing: 2000 mm
Longitudinal length in Z: 1930 mm
Cross-travel in X: 360 mm
Spindle nose: A2 – 8″ ISO
Spindle bore: 105 mm
Maximum spindle speed: 3200 rpm
Spindle power: 22/36 Kw
Multifix turret
Chip conveyor
Year 2002
CNC NUM PL + S (dual keyboard: conversational + iso)
Dimensions: 2510*5800*2130 (width*length*height)
