TECHNICAL DATA
max. diameter above the bench: 400 mm
max. diameter over the trolley: 350 mm
maximum machinable diameter between tips: 220 mm
distance between tips: 1130 mm
12-station turret : VDI 30
X x Zstrokes : 235 x 915 mm
maximum bar diameter: 52 mm
counterpoint sleeve stroke: 150 mm
type of the counter point : MK4
spindle speed: 0 – 3000 rpm
spindle power: 15 kW
total power: 34 kW
dimensions: 2800x2200x2100 mm
weight: 5500 kg
EQUIPMENT
NUM PL+S3 CNC control
manual counter point
lubrication tank with pump
automatic centralized lubrication
LADNER chuck 3 jaws manual
Set of 15 VDI 30 tool holders
