Max. workpiece dia. 700 mm
Max. stroke 300 mm
No. of teeth range 16 – 240
Module range 1,5 – 7
Helix angle +/- 30°.
Pressure angle range 14 – 30 °.
Max. workpiece weight 300 kg
Max. grinding wheel dia. 400 mm
Min. grinding wheel dia. 280 mm
Grinding heel width 84/104 mm
Grinding wheel speed:
– grinding 1650 rpm
– profiling 90 rpm
Workstück infeed, stepless 10-300 mm/min
Tangential movement of workpiece 70 mm
Electrics 380/50 V/Hz
Weight of the m/c approx. 7.5 to
