TOYODA GL7P 100 cylindrical grinding machine
Serial number RC-7485
Passage under tip 400 mm
Max. distance between warehouses 1000 mm
Maximum grinding diameter 300 mm
Max. piece weight 300 kg
Marposs system for diameter measurement
Workpiece probing system for length start
Single point trainer
Automatic bezel
Maximum grinding wheel diameter 915 mm
Grinding wheel bore diameter 304.8 mm
Maximum grinding wheel width 160 mm
Surface speed 45 m/s
Stroke in X 1172.3 mm
Rapid traverse speed 15000 mm/min
Spindle speed 32 to 630 rpm
Tailstock stroke (hydraulic) 60 mm
Grinding wheel motor power 22 Kw
Spindle motor power 1,5 Kw
Central filter volume 350 l
Floor space 4400 x 3900 mm
Net weight 10300 Kg
