Nominal workpiece diameter 130 mm
Nominal module 3 mm
Maximum axial slide travel 250 mm
Hob swivel angle +/- 45
Maximum workspindle speed 1000 rpm
Maximum hob diameter 80 mm
Maximum hob length/total length 170/245 mm
Maximum hob shift travel 170 mm
Hob drive 14kW
Maximum hob speed 3000rpm
Table surface diameter 160 mm
Machine weight 10 000kg
Chamferring and deburring unit type ZEA 4 integrated
