Capabilities:
Table surface 1700 X 800 mm
Strokes 1600 x 800 x 800 mm
Table load capacity 2000 kg
T-slot 5 x 18 mm
Distance spindle nose / table 200 to 1000 mm
Distance between spindle centre and column 900 mm
Spindle:
Spindle nose type BT 40
Spindle power 22 / 26 kw
Torque 200 Nm
Spindle speed 12 000 rpm
Tool magazine :
Type Random 24 tools
Footprint :
Length 4680 mm
Width 3250 mm
Height 3100 mm
Weight 16T5
Installed capacity 40 Kva
Equipment :
Screw chip conveyor
Spindle center watering 20 bar
Washing of casings
Automatic lubrication
Rigid tapping
Option Ai nano interpolation
Automatic shutdown system
Measurement rules
Documentation
Technical description without guarantee, only for information purposes
