TECHNICAL CHARACTERISTICS
Max. diameter cutting length: 1,250 mm
Cutting width: 600 mm
Max. module : 16
Min. module : 2
Maximum size of the hob: 240 x 280 mm
Table diameter: 1,020 mm
Speeds: 28 – 200 rpm
Axial feed rates: 0.28 – 8 mm/min
Radial feed rates: 0.1 – 2 mm/min
Tangential feeds: 0.16 – 4 mm/min
Stand tilt – left/right: +/- 45
Main motor power: 5 / 19.5 kW
Power of the rapids motor: 12,5 kW
Max. diameter of the part without tailstock: 1,250 mm
Max. diameter of the part with tailstock: 800 mm
Weight of the machine : 16,2 T
Machine dimensions approx. 4.5 x 2.1 x h 3.3 m
EQUIPMENT :
Strawberry shafts
Spare gears
