Features technical :
Max depth: 25 mm
Max. flank diameter :
Ratio 10-1 : 460 mm
Ratio 2-1 : 406 mm
Ratio 1-1 : 324 mm
Spindle bore diameter: 78 mm
Spindle nose diameter: 140 mm
Max. diameter from center to spindle nose: 343 mm
Tilt angle min/max: 5°/84
Max ratio: 10-1
Spiral angle: 30°.
Number of teeth min/max: 5/175
Tool speed: 20-115 rpm
Advance: 9-80 seconds
Dimension: 1905 * 289 mm
Weight: 10,773 kg
